DNM PUBLIC ADDRESS AMPLIFER PA 6240
PUBLIC ADDRESS AMPLIFIER
₹27140.00
DNM PUBLIC ADDRESS AMPLIFER PA 6240
This amplifier is ideally suited for background music applications in offices, restaurants, places of worship, gymnasiums, homes, etc.
Amplifier can be connected to multiple speakers having built in line matching transformers
Built-in usb + fm receiver and Bluetooth
3 microphone inputs with mic 1 as priority input
Microphone inputs have echo, repeat & delay functions
2 aux input
Master volume, active bass & treble tone controls
Chime function for announcements and siren function for emergency human evacuation
6 zones output(on the 100v line) with stepped volume control for each zone
Aux out available to daisy chain amplifiers or to connect an active subwoofer
High performance toroidal transformers for mains and output
Brushed alluminium anodised panel with alluminium knobs offering a rich luxurious finish
SPECIFICATIONS
POWER OUTPUT | 240 WATTS |
POWER SUPPLY | 230V, 50Hz |
TOTAL HARMONIC DISTORTION | ≤0.3% @ 1KHz |
SENSITIVITY | 1/4″ PHONE JACK (UNBALANCED) MIC 1 TO MIC 3 – 0.5mV @ 600 OHM |
AUX IN | 650mV |
LINE OUT | 1V |
FREQUENCY RESPONSE | 50 Hz – 18KHz +/- 3dB |
AC POWER CONSUMPTION | 480 WATTS |
OUTPUT | 8 OHM, ALL 6 ZONES 100V OUTPUTS |
SIGNAL TO NOISE RATION | >85 dB |
VOICE PRIORITY MUTE | MIC 1 |
TONE | BASS 100 Hz +/- 1- dB TREBLE 10 KHz +/- 10 dB |
DIMENSIONS | 480 mm(W) x 340 mm(D) x 90 mm(H) |
Note : As part of our continuing programme to improve the design and quality of our products we shall be free to make changes in the design and specifications without any notice.
