Description

Bring both music and movies to life with true high fidelity.

The JBL MA310 is an AV Receiver that delivers extraordinary performance with 4K HDMI specifications for a supreme home cinema experience. Seamlessly integrate your smart TV or projector with 4 HDMI inputs and 1 output, plus ARC. With native 5-channel decoding of Dolby and DTS formats, the MA310 can deliver incredible cinema experiences. It is designed with a passion for music and movies, bringing both to life with true high fidelity. Additional music content can be accessed via Bluetooth. The MA310 features five channels of low noise Class D amplification for real world power to all channels.

General Specifications

HDMI Audio Return Channel

Yes

4K HDMI input connectors (HDMI 2.0,HDCP 2.2 up to 4K/60Hz Ultra HD)

4

HDR 10

Yes

Pure Direct

Yes

EZ Set EQ

Yes

Digital signal processing

up to 24-bit/192kHz

Mains voltage

110 – 240V, 50–60Hz

Max. power consumption

200W

Standby power consumption

<0.5W

Audio Specifications

Channels

5.2

FTC Rated Output Power (20Hz– 20kHz, 2 channels driven, 1% THD max, 8Ω)

50W

Rated Power @ 8Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max)

60 W RMS

Rated Power @ 4Ω (20Hz – 20kHz, 2 channels driven, 0.5% THD max)

100 W RMS

Dimensions incl. feet and speaker terminals (H x W x D)

4.3” x 17.0” x 13.7” (109.2mm x 432.0mm x 347.6mm)

Weight

11.3lb (5.1kg)

Extraordinary audio and video performance

5.2-channel AV receiver that delivers extraordinary audio performance with 4K video for a supreme home cinema experience.

Intuitive setup with a minimalist modern design

Seamless integration with smart TVs, gaming consoles, streaming, cable boxes and more with 4 HDMI inputs and 1 output, plus ARC.

High-performance immersive surround sound

Native 5-channel decoding of Dolby and DTS formats.
