The flagship speaker of the Studio 6 line

The JBL Studio 698 is the flagship floor-standing speaker of the company's impressive Studio 6 lineup. It features dual 8" PolyPlas® woofers in a double-ported enclosure for deep, powerful bass, plus a dedicated 6" midrange driver. High frequencies are handled by a 1" horn-loaded tweeter with HDI (High Definition Imaging) waveguide technology that delivers detailed sound across a wide listening area.

JBL recommend giving this speaker high-current amplification from a quality power amp or integrated amplifier for best performance. Dual binding post speaker terminals allow bi-amping or bi-wiring.

Built on JBL's storied audio heritage

JBL famously pioneered horn-loaded compression drivers in speaker arrays at large concert venues — they're able to fill space with clear sound in a way a standard dome tweeter can’t.

The cornerstone of the Studio 6 Series' distinctive sound is JBL's 1" compression driver mated to a High-Definition Imaging (HDI) horn. The proprietary design helps this speaker deliver crystal-clear high frequencies throughout your room.

Product highlights:

• 3-way design

• 1" compression driver with HDI (High Definition Imaging) waveguide technology for clear highs across a wide listening area

• 6" PolyPlas® midrange driver for engaging detail with instruments and vocals

• dual 8" PolyPlas® cone woofers for deep, powerful bass

• bass-reflex cabinet design with dual rear-firing ports

• frequency response: 36-40,000 Hz

• sensitivity: 90 dB

• impedance: 6 ohms

  • high-current amplification from a quality power amp or integrated amplifier is recommended for best performance

• power handling: up to 250 watts

• two sets of binding post speaker terminals allow bi-amping or bi-wiring

• removable magnetic grille

What's in the box:

• Floorstanding loudspeaker

• Grille

• 4 Spike feet

• 4 Washers

• 4 Locking-collars

• 4 Foot-pads

• 2 Jumper-straps (pre-installed)

• Owner's Manual

• Warranty Card
